    Blowing Filling And Capping Integrated Machine For 18,000 BPH Beverage Aseptic Production Line

    Ask Lasest Price
    Brand Name : Peiyu
    Model Number : customized
    Certification : CE,ISO9001:2008,High-tech enterprise
    Price : Individual quotation according to different requirements
    Payment Terms : T/T,L/C
    Supply Ability : 30 pcs per month
    Delivery Time : 30-40 workdays
    • Product Details
    • Company Profile

    Blowing Filling And Capping Integrated Machine For 18,000 BPH Beverage Aseptic Production Line


    Blowing, Filling & Capping Integrated Machine for 18,000 BPH Aseptic Beverage Production Line

    Shanghai Peiyu Packaging Technology Co.,Ltd.

    Advanced Aseptic Packaging Solution for High-Speed Beverage Production

    Our Blowing, Filling & Capping Integrated Machine is designed for high-speed aseptic beverage production, achieving 18,000 bottles per hour (BPH). Ideal for glass bottle beverages, this fully automated system integrates bottle washing, filling, and capping into a seamless production line, ensuring hygienic, efficient, and precise packaging for carbonated drinks, beer, juices, and other liquid products.

    Key Features & Advantages

    1. High-Speed & Efficient Production

    • 18,000 BPH capacity – Optimized for large-scale beverage manufacturing.

    • Gravity filling system ensures accurate liquid level control.

    • Servo motor-driven for smooth, high-precision operation.

    2. Superior Hygiene & Aseptic Performance

    • Stainless steel (304) contact parts – Corrosion-resistant & easy to clean.

    • High-pressure bottle washing with US-made spray nozzles for thorough internal/external cleaning.

    • Aseptic filling environment prevents contamination.

    3. Precision Capping Technology

    • Japanese-designed capping heads with dual-cam control for secure sealing.

    • Servo-driven capping ensures consistent torque & thread alignment.

    • Automatic cap sorting & detection (missing cap alarm).

    4. Robust & Reliable Design

    • Heavy-duty carbon steel frame with stainless steel panels.

    • Overload protection prevents mechanical damage during jams.

    • Automated lubrication system extends machine lifespan.

    5. Smart Control & Monitoring

    • Pro-Face touchscreen HMI for real-time adjustments & diagnostics.

    • Fault detection & production counting for optimized efficiency.

    • Compatible with Industry 4.0 for smart factory integration.

    Technical Specifications

    ModelLDXGF24-24-8
    Capacity6,000 bottles/hr (500ml beer) / 8,000 cans/hr (500ml carbonated)
    Stations24 washing / 24 filling / 8 capping
    Air Pressure0.7 MPa
    Water Consumption1.5 tons/hour (recyclable)
    Power3 kW (main motor)
    Dimensions3500×2800×2700 mm
    Weight7500 kg

    FAQs

    Q: What types of beverages can this machine handle?

    A: Suitable for beer, carbonated drinks, juices, and other liquid beverages in glass bottles or cans.

    Q: Is the machine compliant with international hygiene standards?

    A: Yes, it meets FDA & EU food safety standards with 304 stainless steel construction and aseptic filling technology.

    Q: What is the lead time for delivery?

    A: 60 working days after deposit confirmation and sample approval.

    Q: What after-sales support is provided?

    A: 12-month warranty (24 months for control systems), 48-hour on-site support, and lifetime technical assistance.

    Q: Can the machine handle different bottle sizes?

    A: Yes, it supports quick changeovers for various bottle/cap sizes with minimal downtime.

    Why Choose Our Integrated Filling Machine?

    ✔ Ultra-high-speed production (18,000 BPH)
    ✔ Aseptic & contamination-free filling
    ✔ Precision capping with servo control
    ✔ Low maintenance & energy-efficient
    ✔ Global support & warranty coverage

    Ideal for beverage manufacturers seeking a high-performance, automated packaging solution. Contact us today for a quote!
